Tri Axle Heavy Duty Drop Deck
- Suitable for Road Train Applications
- Overall Length: 13.73m (45’)
- Overall Width: 2.50m
- Aggregate Trailer Mass (ATM) 41,000 kg
- King Pin: 50mm bolt in type (Neck to suit Tri Dolly)
- Skid Plate: 10mm Fixed
- Landing legs: Holland 2 speed c/w skid feet
- Suspension: Hendrickson Intrax AAT250 U/S Air Bag c/w Raise Lower valve & Analog Weight Gauge
- Axles: Parallel Bearings HLX7 Enclosed Cam Shafts & Auto Slack Adjusters
- Hub & Drum: 10 stud steel Grease 285pcd Drum Brakes
- Tyres: (13) only 275/70R22.5 tubeless
- Wheels: (13) only 10 steel stud 285pcd
- Main Frame: No.2 Main Fabricated “I” Beam chassis, c/w all necessary cross members, stiffeners & Reinforcing
- Coamings: 125 × 65 coaming Rails c/w Gate Pockets
- Load Racks: 1.5m removable front & rear: Nil side gates
- Flooring: 3mm Checker plate floor to Top deck 5mm Check plate floor to bottom deck, c/w pipe style chaining tie down points & Load Stakes pockets (4 per side of each)
- Twist Locks: 3-way twist locks to suit 1 × 40’ – 1 × 20’ – 2 × 20’ Containers
- Complete with Container Stools and Stool Storage
- Load Stakes: 8 Stepped Load stakes with spring bolt retainer and under floor storage
- Tow Coupling: Road Train Ringfeeder fitted to rear of Trailer c/w all air & electrical fittings
- Ramps: Ramps (900 × 3100) c/w single stage hydraulics c/w nylon self-lubricating pivoting bushes – with wind holes
- Beaver Tail: Fabricated type fitted at rear c/w electric power pack – trickle charge
- Top Deck Ramps: Slide out top deck ramps fitted c/w prop support leg and storage
- Toolbox: 2 × 1200mm “sealed & lockable” fitted to LHS
- Water tank: One only “plastic” type 60Lt
- Tyre Carrier: Thru mains, c/w chains- restraints
- Mud Guards: Quarter Guards c/w Flaps fitted front and rear of suspension
- Mud Flaps: Full width across rear bumper
- Brakes: ADR 38 system including EBS brakes
- Electrics: In conduit to comply with Dangerous Goods and Road Train requirements
- Hubometer: Fitted to RHS centre axle
- Lighting: Full set of LED lights fitted c/w Revolving Rear light
- Signage: Oversize and Road Train/Long Vehicle at rear
This trailer is available for hire.
Price: POA
